Bimetal Steam Trap
Short Description:
Product name: Bimetal Steam Trap
Size：DN15 – 50
Pressure：1.6- 4.0Mpa
Material：WCB,CF8,CF8M
Body Material: A105
Connection: Flange,Internal Thread,Socket Welded
Temperature:<=220℃
Media: Steam,Condensate Water
Product name: Bimetal Steam Trap
Features:
1.This type of steam trap is applied with bimetal strip which expands with heat and contracts with cold in order to drain water and prevent steam.
2.This steam trap is small in size and light in weight.With easy installation,it can be installed in any angle.
3.The air and condensation water can be discharged rapidly during the initial operation of valves without any air lock situation.
4.It is sensitive in induction,and can be drain water without any noise,which is also very strong in resistance to corrosion.
Application:
Bimetal strip steam trap can be applied in the filed of power station,petroleum,chemical industry,paper making,textile,etallurgical and other industrial steam heating system.
